Here is the Big Fish 3000-Watt Fish House Inverter Package, it includes the following to Do-It-Yourself including a 7" Display to track your power use!

2 sets of 6' of Red and Black 1/0 AWG for the battery switch to inverter connection, This is a two positive, two negative required installation, do not use just one set of leads, both are required!

Two 4' sets of Yellow 1/0 AWG to attach to metal frame of shack to be doubled up

8' of 8/3 Triplex Wire to attach to your A/C Panel

Victron Bluetooth 500 Amp Smart Shunt

BEP Pro Installer 400A Battery Switch

.9 Meter RJ45 Network Cable x 2 for Bluetooth Smart Dongle and Cerbo GX

Longer cables are available to match your installation

Includes Two MRBF Terminal Blocks, each with a 300Amp Fuse for the Inverter

A separate switch is recommended with a 60 Amp Fuse for a DC Panel powering a lift bed or slide outs, 8 AWG must supply the fuse panel if using a 60-amp fuse (not included but it is usually wired already with 8 AWG Wire) When 10 AWG is supplying the Panel, the fuse should be switched to 30 Amps. (contact us)

Your A/C Panel Supply Line from the Receptacle can be reused if it is long enough but must be moved to the input side of the Multiplus, if it is not long enough replace it from the Receptacle to the inverter with 10/3 for a 30amp Receptacle (Sold by the foot on our webpage) Do not extend the Input or Output wires!  If using at 50 amps Ac Wire must be rated for it.

Find a suitable mounting location for the inverter where it will receive enough ventilation and hook up the Pre labeled wires to match the diagram!  Do not extend the included DC Cables, If you need longer cables order the 12 foot kit or contact us!

Dc and Ac Electrical experience is required and if unsure of your skill level feel free to contact us about your installation or to schedule us to do the labor for you.
